Hubbell 69HBU2 Heavy Duty Air Compressor Pressure Switch, 100-125psi, with Unloader, 3/8" NPT

Hubbell 69HBU2 Heavy Duty Air Compressor Pressure Switch, 100-125psi, with Unloader, 3/8" NPT

The rugged 69HBU2 pressure switch is pre-set to kick on at 100psi and turn off at 125psi which is extremely common for climate control applications or fire suppression applications. 69HBU2 includes an unloader line for 1/4" tubing or refrigeration copper. This switch is designed for the demanding requirements of larger, heavy duty commercial compressors. This is a more robust switch than the 69HAU2 and capable of handling larger motor horse poweres.

The 69HBU2 includes a sturdy painted steel case and cover resists the harsh conditions encountered in industrial applications.

• Connection for unloader line
• UL Listed and CSA Certified
• Designed for Demanding Requirements of Larger Heavy Duty Commercial Compressors
• Sturdy Painted Steel Case and Cover Resist Harsh Conditions

69HBU2 Specifications:

• Default factory pressure setting: 100-125psi
• Minimum Close Cut In: 10psi
• Maximum Open Cut Out: 125psi
• Differential Range: 20-35 psi
• Motor HP Max on 115v - 2hp
• Motor HP Max on 230v 1phase - 5hp
• Rated for 1phase and 3 phase applications.
